H Wetherel (Sr.) Planes
Henry Wetherel Sr. (1729-1797)
Norton, MA and Chatham, CT
shop joiner and blacksmith
​
(Connections probable with Elisha Clark (strong parallels in the plane design details (especially the jointer totes)) and with Jacob Austin (use of the same "In Norton" name stamp).
H * Wetherel / In * Norton; C imprint (first imprint - separate from the more common A imprint). Finial is relieved but more rounded than the more common wedge finial on imprint A planes.
Courtesy of Dick Rosenblatt.
![](https://static.wixstatic.com/media/f51dec_a2df727a47ba49b283e096a3cec98fc8~mv2.jpg/v1/fill/w_480,h_600,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/f51dec_a2df727a47ba49b283e096a3cec98fc8~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_24a4619144e74a8ea69e5099cc563cf0~mv2.jpg/v1/fill/w_108,h_62,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_24a4619144e74a8ea69e5099cc563cf0~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_e88998bc80784e19895f58957c77aca5~mv2.jpg/v1/fill/w_108,h_36,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_e88998bc80784e19895f58957c77aca5~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_0b12d5b716604757afaed5cda44ccadc~mv2.jpg/v1/fill/w_108,h_48,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_0b12d5b716604757afaed5cda44ccadc~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_08503e6247664ff7bb7adb77f6ff2982~mv2.jpg/v1/fill/w_108,h_59,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_08503e6247664ff7bb7adb77f6ff2982~mv2.jpg)
H Wetherel / In Norton; A imprint (pre 1779)
Early chamfer stops have a tipped starting edge with a curved return followed by a continuous long flute. The typical molder wedge finial has less height than the later wedges and thus appears less rounded. Molders typically made of birch and are 9 3/4" long.
![](https://static.wixstatic.com/media/f51dec_3c4d70929c94434fbdc8aa71c397a3c7~mv2.jpg/v1/crop/x_152,y_0,w_493,h_595/fill/w_92,h_112,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_3c4d70929c94434fbdc8aa71c397a3c7~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_04993c0b39c649c2bfdfb63fdfdd871e~mv2.jpg/v1/fill/w_108,h_57,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_04993c0b39c649c2bfdfb63fdfdd871e~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_baf344de6e374b3caa81f79ac8af045a~mv2.jpg/v1/crop/x_658,y_0,w_837,h_2739/fill/w_183,h_599,al_c,q_80,usm_0.66_1.00_0.01,blur_3,enc_auto/f51dec_baf344de6e374b3caa81f79ac8af045a~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_f2711f228adb423d9ed13f17364fa124~mv2.jpg/v1/fill/w_109,h_131,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_f2711f228adb423d9ed13f17364fa124~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_63efd7eb3da74466ac8e64be0120674f~mv2.jpg/v1/fill/w_108,h_81,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_63efd7eb3da74466ac8e64be0120674f~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_1a02e994ee194701b1ab3556bd83911f~mv2.jpg/v1/fill/w_108,h_86,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_1a02e994ee194701b1ab3556bd83911f~mv2.jpg)
H Wetherel / Chatham; B imprint (post 1779)
Later chamfer stops end with a simple turn out. The molder wedge finials have more height and appear more rounded. Cartouche elements present as with H Wetherell Jr.
![](https://static.wixstatic.com/media/f51dec_47dfc74933cc49e68f13e61f9c075e26~mv2.jpg/v1/crop/x_216,y_0,w_441,h_632/fill/w_83,h_119,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_47dfc74933cc49e68f13e61f9c075e26~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_0e31d85095f64309bd2973d13788e3aa~mv2.jpg/v1/fill/w_108,h_90,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_0e31d85095f64309bd2973d13788e3aa~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_49338a79f6914ec4ae595d2f64cff877~mv2.jpg/v1/fill/w_108,h_64,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_49338a79f6914ec4ae595d2f64cff877~mv2.jpg)
![](https://static.wixstatic.com/media/f51dec_c86117060ac242c7b98a21960230dbb8~mv2.jpg/v1/fill/w_108,h_71,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/f51dec_c86117060ac242c7b98a21960230dbb8~mv2.jpg)
